| BUTT-WELDING PIPE FITTINGS DETAILS |
| MATERIAL | Carbon Steel : |
| ASTM, A234WPB, A234WPC, A420WPL6 ,Q235,10#, A3, Q235A, 20G,16Mn, |
| DIN St37, St45.8, St52.4,St.35.8,St.35.8. |
| Stainless Steel: |
| 1Cr18Ni9Ti 0Cr18Ni9 00Cr19Ni10 0Cr17Ni12Mo2Ti |
| 00Cr17Ni14Mo2 304 304L 316 316L |
| Alloy Steel: |
| 16Mn Cr5Mo 12Cr1MoV 10CrMo910 15CrMo 12Cr2Mo1, |
| A335P22 St45.8, ASTM A860 WPHY X42 X52 X60 X70 |
| STANDARD | ASTM / JIS / DIN / BS / GB/GOST |
| MODEL | 1.Tee(Straight and Reducing) 2.180 DEG Return |
| 3.Elbow (45/90/180 DEG) 4.Cap |
| 5. Reducer(Concentric and Eccentric) |
| TYPE | Seam Or Seamless |
| ELBOW DEGREE | 45 degree, 90 degree, 180 degree |
| SURFACE | Black Paint, Anti Rust Oil, Hot-Dipped Galvanize |
| WALL THICKNESS | SCH5S,SCH10S,SCH10,SCH20,SCH30,SCH40,STD,XS,SCH60, |
| SCH80,SCH100,SCH120,SCH140,SCH160,XXS,2MM |
| SIZE | 1/2"-48"(Dn15-Dn1200) |
| CONNECTION | Welding |
| SHAPE | Equal, Reducing |
| CERTIFICATE | ISO9001 |
| APPLICATION | Petroleum, chemical, power, gas, metallurgy, shipbuilding,
construction, etc |
| Customers’ drawings or designs are available. |
| PACKAGE | 1> 1/2" - 2" in cartons. |
| 2>Above 2" in wooden cases. |
| Big size is workable by pallets. |
| DELIVERY DETAILS | According to the quantities and specifications of each order. |
| Normal delivery time is from 30 to 45 days after receiving the
deposit. |
There are many types of pipe fittings,Divided by purpose:
1. The pipe fittings used to connect the pipes are: flanges,
unions, pipe clamps, clamps, clamps, hose clamps, etc.
2. Fittings that change the direction of the pipe: elbows, elbows
3. Fittings that change the diameter of the pipe: reducing diameter
(reducing pipe), reducing elbow, branch pipe stand, reinforcing
pipe
4. Increase the pipe fittings of the pipeline branch: three-way,
four-way
5. Pipe fittings used for pipeline sealing: gaskets, raw material
tapes, hemp, flange blind plates, pipe plugs, blind plates, heads,
welding plugs
6. Pipe fittings used for pipeline fixing: snap ring, towing hook,
lifting ring, bracket, bracket, pipe clamp, etc.
Divided by connection:
1. Welded pipe fittings
2. Threaded pipe fittings
3. Tube fittings
4. Clamp fittings
5. Socket pipe fittings
6. Bonding pipe fittings
7. Hot melt pipe fittings
8. Curved double melting pipe fittings
9. Rubber ring connection type pipe fittings
