Double Column Angle Cut 45 Degree Mini Bandsaw Machine Semi Automatic

Semi Automatic Angle Cut 45 Degree Band Saw Machine

1. Double column structure, vertical lifting, high stability;

2. According to the user's request, the rotation angle can be set by the user. When the workpiece is not moving and the whole machine is rotated, the angle of any angle between 0° and 45° can be completed, and the operation is simple;

3. Cutting speed hydraulic control, stepless speed regulation;

4. The workpiece is clamped to hydraulic clamping, which is easy to operate;

5. Customizable three-way hydraulic clamping device.

Type	G300
Cut capcity W*H (mm)	90° round 300
Cut capcity W*H (mm)	square 300*400
	45° round 280
	square 280*280
	60° round 280
	square 180*300
Bundle cutting W*H (mm)	Max. 200*90
Bundle cutting W*H (mm)	Min. 100*20
Saw belt size(mm)	3505270.9
belt line speed(m/min)	15-80 frequency control
Main generator power(kw)	2.2
Hydraulic generator power(kw)	0.75
Cooling generator power (kw)	0.09
Working clamp style	Hydraulic
Saw belt tighten style	Hydraulic
Main trasmit structure	Turbine
Loading style	Extra roller
Volume of oil case (L)	60
Volume of water case (L)	40
Max single feeding (mm)	400
Working table height (mm)	650
Weights of machine (kgs)	1100
Packing dimensions(mm) LMH	175022001450

1, when the sawing is completed, it will automatically stop and raise the saw frame for high efficiency operation.
2, the saw belt can adjust the load to ensure that the band saw does not fatigue and the feed rate is steplessly changed, and can be adjusted to the best cutting effect.
3, when the sawing machine can cut the cutting speed according to the material structure properties, the saw blade can effectively improve the service life of the saw blade.
4, hydraulic tensioning saw blade (easy operation and improve work efficiency)
5, saw blade break automatically stop (safe)
