Portable Single Column BS 712N Metal Cutting Bandsaw Machine

Product Categories

SHEAN (CANGZHOU) CORP LTD

Contact Now

Add to Cart

Portable Single Column Metal Cutting Bandsaw Sawing Machine

Features:

1. Hydraulic clamping vice

2. Swivel on both sides

3. Electric coolant system

4. High-capacity band control by two-speed motor

5. Vertical rotation on bolt with adjustable tapered bearings without backlash

6. Band stretching is obtained by electro-mechanical blade tension with micro switch

Automatic band saw machine Features:

1. Automatic CNC sawing machine, suitable for mass production continuous cutting

2. Cut-off length setted by screen, accuracy to 0.1mm, ensure the precision

3. Touch screen operation, man-machine interface in stead of buttons, easy to operate

4. High precision PLC control , 5 groups of sawing data available and improve sawing efficiency

5. Adoption of grating ruller feed system, single max feed stroke 420mm (length customization available)

Type	BS-712N
Cut capcity W*H (mm)	90° round 178
Cut capcity W*H (mm)	square 178*305
	45° round 127
	square 120*125
Bundle cutting W*H (mm)	Max. 200*90
Bundle cutting W*H (mm)	Min. 100*20
Saw belt size(mm)	3505270.9
belt line speed(m/min)	15-80 frequency control
Main generator power(kw)	2.2
Hydraulic generator power(kw)	0.75
Cooling generator power (kw)	0.09
Working clamp style	Hydraulic
Saw belt tighten style	Hydraulic
Main trasmit structure	Turbine
Loading style	Extra roller
Volume of oil case (L)	60
Volume of water case (L)	40
Max single feeding (mm)	400
Working table height (mm)	650
Weights of machine (kgs)	145/178
Packing dimensions(mm) LMH	15405901150
