Kgps Medium Frequency Power Supply For Machine Induction Heater
Features of the KGPS Kgps Medium Frequency Power Supply For Machine Induction Heater:
• The furnace body is made by thick aluminum alloy shell to reduce
the magnetic leakage and ensure furnace body strength.
• The thick T2 standard tube is taken use for induction coil to
provides high melting efficienccopper y.
• Open type furnace hearth reduces moisture,and design cooling
rings on the bottom, which extend the furnace lining life time.
• The titling is controlled by reducer gear box. The remote control
panel can set the furnace in any position when titling. The max
tilting angle is 95 degrees.
More Products except of our Kgps Medium Frequency Power Supply For Machine Induction Heater :
Elbow Forming Machine , Elbow Cold Forming Machine ,
Pipe Bending Machine , Hydraulic Press Machine ,Pipe Expanding
Machine , Tee Forming Machine , Pipe Beveling Machine , Shot
Blasting Machine , Band Saw Machine , Medium Frequency Power Source
, Pipe Fitting Mould , Steel Pipe Fittings , Aluminum melting
furnace IGPS , KGPS power supply , Ciosed cooling tower
Advantages of Our Heiyan Kgps Medium Frequency Power Supply For Machine Induction Heater
1. Energy saving:
The power factor reaches 0.99 under the condition of full power
output. The integrated circuit board is adopted and the current and
voltage are adjusted internally. The core components are high
performance, high density and large-scale ASIC integrated circuit
produced in the United States, which are digitized. The rectifier
trigger part does not need any adjustment, and has the advantages
of high fraud reliability, high pulse symmetry, strong
anti-interference ability and fast response speed.
2. Big reactor design:
Strong filtering ability, greatly reduce harmonic pollution to the
grid, suppress the current mutation, protect the transformer.
3. Large section area of current carrying discharge:
Select 8×60 copper row, large cross-sectional area, strong current
carrying capacity, reduce heat.
4. Cabinet uses RITTAL brand:
Durable and beautiful
5. Appliances: SCHNEIDER brand
6. Button: IDEC brand
7. Insulating plate:Durable and high insulation grade, beautiful
8. Water segregator: Stainless steel
9. Cooling water pipe: Specially customized, high temperature and
high pressure
10. Inverter increase resistance and capacity absorption: it can
effectively suppress the instantaneous oscillation and
high-frequency current of operating overvoltage, so that the
waveform of overvoltage becomes slow, the steepness and amplitude
are reduced, plus the damping effect of resistance, so that the
high frequency oscillation rapidly attenuates.
NOTE:
Please do not touch any exposeed electric components and induction
coils when it is starting work .Please close system if repair or
moving . Refuse electrocute!
Brife Introduction of Kgps Medium Frequency Power Supply For Machine Induction Heater:
KGPS Series Thyristor transducer is a quiescent device to change
Three phase alternating current energy into Single phase
Intermediate Frequency electric energy. This kind of device is
apply to induction diathermy,melting,quenching.
Production Description of Kgps Medium Frequency Power Supply For Machine Induction Heater
1) Turn on and turn off easily,and power failure.
2) Adopt constant power to control the circuit, maintain constant
power while malting, and keep faster melting rate.
3) Set up over voltage, over current and water deficient protector,
and run safely.
4) The motherboard adopts CAD technology, integrated circuit board,
low-fault-rate, easy-manipulating,effortless maintenance.
5) Zero voltage starts up softly, high initial over, no impact for
the electric network.
6) Apply to melting ferrous metal and non-ferrous metal like
copper, aluminum, brass, steel,iron,stainless steel etc...
Technical Parameter of Kgps Medium Frequency Power Supply For
Machine Induction Heater:
| Model | Input power(kw) | Semlting capacity(T) | Smelting(T/H) |
| KGPS-50 | 50 | 0 | 0 |
| KGPS-100 | 100 | 1/9 | 1/9 |
| KGPS-160 | 160 | 1/7 | 1/5 |
| KGPS-250 | 250 | 1/4 | 1/3 |
| KGPS-300 | 300 | 2/7 | 3/8 |
| KGPS-400 | 400 | 1/2 | 5/9 |
| KGPS-500 | 500 | 3/4 | 7/9 |
| KGPS-750 | 750 | 1 | 1 |
| KGPS-1000 | 1000 | 1 1/2 | 1 1/2 |
| KGPS-1400 | 1400 | 2 | 2 |
| KGPS-2000 | 2000 | 3 | 2 4/5 |
| KGPS-3000 | 3000 | 5 | 4 2/7 |
| KGPS-4000 | 4000 | 7 | 7 |
| KGPS-4500 | 4500 | 8 | 7 1/2 |
| KGPS-6000 | 6000 | 10 | 10 7/9
|
APPLICATIONS of our Kgps Medium Frequency Power Supply For Machine Induction Heater:
Preheating of forging, Heat treatment, Brazing, Melting, Shrink-fit
and preheating of pipe bending,Elbow Pushing,Pipe Expanding
APPLICATIONS of our Kgps Medium Frequency Power Supply For Machine Induction Heater:
A. Heating (hot forging, hot fitting and smelting):
B. Heat Treatment (surface quench):
It is mainly aims to change the rigidity of the metal materials
through the heat treatment to work pieces. Detail applications are
stated as follows:
C. Welding (braze welding, silver soldering and brazing)
It mainly aims to melt the solder by heating it to a certain
temperature for the purpose of connecting two types of metals of
the same material and different
D. Annealing (tempering and modulation)
Electric Board
The main control circuit board is the core component of the
machine.high quality. We have many stocks.
Main control circuit board as the main part of the machine, we made
in their research and development, and adopted by the company and
built since the automatic welding and testing equipment to ensure
that each set of machine can achieve the best effect, and we have
main control board in stock lone time, can satisfy the parts supply
problems.
Induction coils
The induction coil inside the furnace body is treated with two
insulations. The first spray of high temperature insulation paint.
The second round of glass fiber tape. The service life of the
treated furnace lining and induction coil will increase by more
than two times.
Features of the our Kgps Medium Frequency Power Supply For Machine Induction Heater :
• Easy operation:
A full time operator specially for power supply is not needed
.There is only one switch for turning on or off and one power
adjustment knob. After started, the only thing that needs to be
done is rotating the power adjustment knob to the largest location,
others are controlled by the device itself.
• Safety protection functions of induction melting furnace:
1. The main circuit and short circuit protection
2. SCR overvoltage protection
3. Main circuit phase fault protection
4. The main circuit phase loss protection
5. Low water pressure protection
6. SCR overcurrent protection
• Highly reliable electrical control board
In the operation, the 3-phase current is balanced. Due to the
advanced design, the 3-phase power supply's sequence could be
connected randomly. Moreover there is no limit to connect to
capacitor cabinet and furnace. All of these jobs can be judged to
be adapted automatically by the device itself. It makes the
installation and maintenance very easily.
